E-SERIES
(May, 2004)
36
STATEMENTSOFCONFORMITY
FIGUREG3 –ROOFPANELREMOVALAREA –E-SERIES
ENDOFROOF
EXTENDEDVAN
ENDOFROOF
EXTENDEDVAN
ORWAGON
REGULARVAN
NOTE: SHADEDAREAREPRESENTSMAXIMUMOPENING INBODYPANELS.
[ ] DIMENSIONSARE INCHES
C
L
OUTEREDGE
OFTROUGH
REGULARVAN
"B" PILLAR
REINFORCEMENT
WINDSHIELD
HEADER
FORWARD
CUTLINE
50.8
[2.00]
SECTIONAT
CLOFROOF
HEADLINERPLANE, FORVEHICLESNOTEQUIPPEDWITH
AFORDHEADLINER, USEAPLANEDETERMINEDBYA
POINTATTHELOWERREAROFTHEWINDSHIELDHEADER
TOTHEMIDPOINTONTHEBPILLARREINFORCEMENT.
203.2
[8.00]
203.2
[8.00]
CUT
LINE
CUT
LINE
FRONT OF
VEHICLE
ENDOFROOF
CUTAWAY
