E-SERIES
(May, 2004)
35
STATEMENTSOFCONFORMITY
E
F
FRONT OF
VEHICLE
THESPOTWELDS ( X ) IN
THISAREAMUSTREMAIN
INTACT.
G
NOTE: SHADEDAREAREPRESENTSMAXIMUMOPENING INBODYPANELS
THESECTIONSSHOWNAREA LARGERSCALE THAN THESIDEVIEW
FOR THEPURPOSEOFCLARITY.
[ ] DIMENSIONSARE IN INCHES
CUTLINE
SECTION EE
SECTION FF
CUTLINE
SECTION GG
CUTLINE
533.4
[21.00]
MAXIMUMWITH
SLIDINGDOOR
711.2
[28.00]
MAXIMUM
WITHCARGO
DOORS
F
G
E
FIGUREG2 –BODYPANELWINDOWREMOVALAREA–E-SERIES (PASSENGERSIDE–R.H.)
