E-SERIES
(May, 2004)
32
STATEMENTSOFCONFORMITY
FIGURED –E-SERIESOCCUPANTPROTECTIONZONE
SRP INFORMATION
POINTA
(SEATPOSITION IS 10.0mm [0.39 IN] FORWARD
(SEATPOSITION ISATTHEMIDPOINT
OFREARMOSTPOSITION)
OFAVAILABLETRAVEL)
A
B
C
D
E
F
MIN.
MAX.
DRIVER –SEAT (VANANDCUTAWAY)
217.8
105.0
384.2
356.0
67.0
937.4
[8.57]
[4.13]
[15.13]
[14.01]
[2.64]
[36.90]
PASSENGER –SEAT (VANANDCUTAWAY)
277.3
103.0
377.0
412.0
65.0
960.1
[10.92]
[4.06]
[14.84]
[16.22]
[2.56]
[37.80]
IMPORTANT:
THETORSOANGLE ISDETERMINEDBY
USINGTHEMETHODSPECIFIED IN
SAE J826 (MAY 1987)
POINTA
D
A
F
C
[ ] DIMENSIONSARE INCHES
E
E
POINTA
POINTA
DRIVER SEAT
PASSENGER SEAT
CL
VEHICLE
B
B
DRIVERSIDEONLY
TORSOANGLE
18 DRIVER
21 PASSENGE
R
SEAT
BASE
SEAT
BASE
CLOUTSIDE
FRONT
FASTENER
CLOUTSIDE
FRONT
FASTENER
THEDIMENSIONS INTHISFIGUREREQUIRETHEVEHICLETOBEAT
DESIGNPOSITION. ECONOLINEVANVEHICLESATDESIGNPOSITION
WILLBE LEVELFRONTTOREAR, ANDSIDETOSIDE, ONTHEUPPER
SURFACEOFTHERIBBEDFLOORPANELFROMTHEB-PILLARREARWARD.
CLOUTSIDE
FRONT
FASTENER
SEATBACK
PIVOT
6.0
[0.24]
510.0
[20.08]
HEEL
POINT
SRP HASA12.7 [0.50] RADIAL
TOLERANCEPERMITTEDFROM
BASESRP
FIGUREC –E-SERIESSEATINGREFERENCEPOINT (SRP)
DONOT INSTALLADDITIONALCOMPONENTS IN THE
SHADEDAREAS, ORALTERORMODIFY THESEAREAS.
