E-SERIES
(May, 2004)
42
STATEMENTSOFCONFORMITY
301
(Continued)
301
(ContinuedNext Page)
†
Temporary removal of the front bumper and front bumpermounting
system during manufacture and reinstallation in accordance with
the instructionsprovided in theFordTruckShopManual shouldnot
adversely affect compliance of the completed vehicle to Standard
301.
OUTBOARD
FRAMEREINFORCEMENT
BACK-TO-BACK
CROSSMEMBERS
LOWERFRAME
FLANGEREINFORCEMENTS
OUTBOARD
FRAMEREINFORCEMENT
FIGUREH–E-SERIESCUTAWAYWITHGASOLINEENGINEANDSCHOOLBUSPREPARATIONPACKAGE
• No other alteration or modification made to the
incomplete vehicle, as manufactured by Ford Motor
Company, and no other components or structure
installed by a subsequent stage manufacturer result
in penetration, separation, or other damage to the
fuel systemor anyportion thereofwhen thevehicle is
tested inanymannerspecifiedbyapplicableprovisions
of Standard 301.
†
• The completed vehicle’s Unloaded VehicleWeight
does not exceed the value designated inTable A for
E-Seriesonpage15corresponding to the incomplete
vehicle’smodel andwheelbase.
301 Thestatementsbelowareapplicable to the following
incomplete vehicle types if the vehicle GVWR is
4536kg [10,000 lb] or less:
• Cutaway
• E-SeriesCutaway (SRW) withDiesel Engine
andSchool BusPreparationPackage
• E-SeriesCutaway (SRW)withGasolineEngine
andSchool BusPreparationPackage
This vehicle, when completed, will conform toStandard
301, Fuel System Integrity, if:
• The following fuel system components as installed
by FordMotor Company are not removed, relocated,
altered, ormodified inanyway except as specified in
the following representations:
– Fuel tank(s) and attachment hardware, including
sendingunit, vapor valve, fuel tankshield, pressure
transducer, and in-tank electric fuel pump
– Fuel filler cap(s), pipe(s), hose(s), and attachment
hardware
– Fuel lines, routing, and attachments
– Vapor line(s)andcarboncanister– (gasolineengine
application)
– Fuel pump
– Fuel filter
– Fuel water separator fuel filter/primer, fuel line
heater, and injectionpump– (diesel engine only)
– Fuel shut off switch (Inertia switch)
– The two Outboard Frame Reinforcements, two
Lower Frame Flange Reinforcements, and two
extraback-to-backcrossmembers,all shownabove,
and all unique to the gasoline engine School Bus
Package.
• No other alteration or modification made to the
incomplete vehicle as manufactured by Ford Motor
Company and no other components or structure
installed by a subsequent stage manufacturer result
in penetration, separation, or other damage to the
fuel system or any portion thereof when the vehicle
is tested in any manner specified by applicable
provisions of Standard301.
†
• The completed vehicle’s Unloaded VehicleWeight
does not exceed the value designated inTable A on
page 15 corresponding to themodel andwheelbase.
