E-SERIES
(May, 2004)
31
STATEMENTSOFCONFORMITY
FIGUREB –E-SERIESFRONTSEAT INSTALLATION
POWERL.H. SHOWN
SEATASY.
N802351-S424
STUD 2REQ’D.
2C24-1561701-A
POWERTRACKA
FRT. ST.
56912-S58
SCREW 4.2 x 19
TAPPING
N800937-S424
NUT&WASHERASY.
2REQ’D.
TORQUE55.0 8.3Nm
N620481-S58
NUTM8 x 1.75HEXFLANGE
TORQUE25.0 3.8Nm
W705944-S424
SCREW2REQ’D.
TORQUE55.0 8.3Nm
+
+
611D02A
STUDCOVER
4REQ’D.
XC25-1560094-B
SUPPORTASY.
SWITCHASY.
ST. CONTROL
F8UB-14A699-A
WIRINGASYSEAT
CONTROLFEED
N801078-S424
SCREWM8 x 1.25HEX
4REQ’D.
TORQUE 25.0 3.8Nm
+
PIABOLT
TORQUE
35.0 6.0Nm
+
JUMPER
F8UB-14A699AA
WIRINGASYSEAT
CONTROLFEED
JUMPER
[29.5 4 ft-lb]
[18.4+ 2.8 ft-lb]
[40.6+6 ft-lb]
[18.4+2.8 ft-lb]
[40.6 6 ft-lb]
-
-
-
-
-
-
-
XL3T-14A701-A
+-
+-
+-
O
O
PRESS
A
CLEARANCE
ZONE
CLEARANCE
ZONE
10
45
O
10
O
15
SIDEVIEW
REARVIEW
CENTEROFVEHICLE
FRONTOFVEHICLE
PRETENSIONERCLEARANCEZONE
579988
SEAT
PASSXC2A-156202-A
BUCKLEASY.
DR. 571485
PASS. 571481
R.H. TRACK
FORSHIPPING
PURPOSESONLY,
ONLY4SCREWS (NO
NUTS&BOLTS)
611D02A
STUDCOVER
4REQ’D.
N800937-S424
NUT&WASHERASY.
2REQ’D.
55.0 8.3Nm
571483DR.
571479PASS.
R.H. TRACK
N011488-S424
STUD2REQ’D.
XC25-1560094-A (MANUAL)
SUPPORTASY.
COVERFRT
ST. PVT.
PIABOLT
TORQUE
40.0 6.0Nm
W705944-S424
SCREW 2REQ’D.
55.0 8.3Nm
F7U-S14A699DB
WIREASY.
2C24-1561755-B (DR.)
HDL.FRT.ST.TRK.
THESHADEDAREAMUSTBEFREEOFOBSTRUCTIONS.
THEBUCKLEMOVESDOWNWARDTHROUGHTHESHADED
ZONEANDMUSTNOTCONTACTANYCOMPONENTWHICH
MAYDEGRADE ITSPERFORMANCE.
IMPORTANT:
DONOT INSTALLADDITIONALCOMPONENTS INTHESHADED
AREA, ORALTERORMODIFYTHISAREA.
VIEWA
+
+
+
[ ] DIMENSIONS ft-lbOR INCHES
[29.5 4 ft-lb]
+
[40.6 6 ft-lb]
+
[40.6 6 ft-lb]
+
-
-
-
-
-
-
DR. 3C34-1561203-A
O/BTRUCKS
E-SERIESPASSENGER (R.H.) SEAT INSTALLATION
E-SERIESDRIVER (L.H.) SEAT INSTALLATION
E-SERIESDRIVER (L.H.) SEATDELETEOPTION
MANUALR.H. SHOWN
SEATASY.
+
N801078-S58
SCREWM8x1.25
HEX 4REQ’D.
TORQUE
25.0 3.8Nm
4C24-15618B47-AA
TRACKASY.
XC2A-1561202-A
PYROTECHNIC
ASY. R.H.
PIABOLT
TORQUE
35.0 5.0Nm
+
COVERFRT.
ST. PIVOT
56912-S58
SCREW 4.2 x 19.0
TAPPING
1C2415466B00A
BRKTCHILDSEAT
N620432-S58
M10HEXNUTHD.
NUTW/WASHER
4REQ’D.
N802351S424
STUD 2REQ’D.
2C24-1562506-A
SUPPORTASY.
(R.H. MNL)
F7US-14A699DB
WIREASY.
2C241561755A
HANDLEFRT. ST.
TRACK
IC24-15618B46-B
TRACKASY.
+
[18.4 2.8 ft-lb]
+
[29.5 4 ft-lb]
-
-
-
-
611D02A
STUDCOVER
4REQ’D.
[40.6 6 ft-lb]
TORQUE 55.0 8.3Nm
N811326S424
SCREW 2REQ’D.
+
-
+
-
