E-SERIES
(May, 2004)
24
205 The statement below is applicable to all incomplete
vehicle types,except theBasic (Stripped)Chassis:
This vehicle, when completed, will conform to
Standard 205, Glazing Materials, if no alterations to
or replacements of the installed glazing materials are
made and if additional glazing materials installed by
a subsequent stage manufacturer conforms to the
requirements of Standard 205.
205 The statement below is applicable to the following
incompletevehicle type:
• E-SeriesBasic (Stripped) Chassis
ConformitywithStandard205,GlazingMaterials, isnot
substantially affected by the design of this incomplete
vehicle: accordingly, Ford Motor Company makes no
representation as to conformitywith thisStandard.
206 Thestatementsbelowareapplicable toall incomplete
vehicle types except the Basic (Stripped) Chassis,
whencompletedasaTruck:
This vehicle, when completed, will conform toStandard
206, Door Locks and Door Retention Components, if
no alterations or adjustments are made to the door,
door pillar structure, door locks, door latches, striker
plates, hinges, and attaching hardware as installed by
FordMotor Company.
Any door added to this vehicle by a subsequent stage
manufacturer must be equipped with door locks and
door retention components that conform with this
Standard.
206 The statement below is applicable to the following
incompletevehicle type,whencompletedasaTruck:
• E-SeriesBasic (Stripped) Chassis
Conformity with Standard 206, Door Locks and Door
Retention Components, is not substantially affected
by the design of this incomplete vehicle; accordingly,
Ford Motor Company makes no representation as to
conformitywith thisStandard.
207,208,209,and210 INFORMATION
For additional information to assist in designing seats,
seat belt systems, andseat belt anchorages that comply
with Standard 207, 208, 209, and 210 applicable to
IncompleteE-SeriesVanandCutaway vehicleswithno
front seatsprovidedbyFordMotorCompany, refer to the
DesignRecommendationsectionof theFordTruckBody
Builders Layout Book for Seat and Lap&Shoulder Belt
System information that is inaddition to the statements
which follow.
207 Thestatementsbelowareapplicable to the following
incompletevehicle typeswhenequippedwith trimmed
front seats:
• IncompleteE-SeriesVanorWagon
• Cutaway
This vehicle, when completed, will conform toStandard
207, SeatingSystems, if noalterations aremade to the
seat assemblies, their anchorages, the floor pan, or
floor pan reinforcements. Any seating system added to
this vehicle must conform to applicable requirements
of this Standard.When the Cutaway is completed as a
school bus, seeStandard 222also.
If the front seat attaching hardware is removed for any
reason, it must be reinstalled to the specifications in
FigureB for E-Series on page 31.
The Incomplete E-Series Recreational Van or the
Incomplete E-Series Wagon may have additional
anchorages for rear seats other than the front driver
and passenger seats.These locations apply to specific
hardware and designated seating positions used in
Ford completed vehicles. If these anchorages are
used without the appropriate Ford seats, seat belt
systems, andhardware,FordMotorCompanymakesno
representationas to conformitywith thisStandard.
207
(ContinuedNext Page)
STATEMENTSOFCONFORMITY
