E-SERIES
(May, 2004)
19
STATEMENTSOFCONFORMITY
108 Thestatementsbelowareapplicable to the following
incompletevehicle type:
• E-SeriesBasic (Stripped) Chassis:
Conformity with Standard 108, Lamps, Reflective
Devices, andAssociatedEquipment, isnot substantially
affected by the design of this incomplete vehicle;
accordingly, Ford Motor Company makes no rep-
resentationas toconformitywith thisstandard.However,
Ford Motor Company does represent that the items
of lighting equipment, when provided in the E-Series
dunnage box attached to the chassis, are designed to
conform to the requirements of Standard 108.
108 CanadianRequirements:
The preceding statements for Standard 108 are
appropriate compliance representations for CMVSS
108, Lighting, and CMVSS 108.1, Headlamps, if this
vehicle is manufactured for sale or use in Canada,
provided:
• No component of the Daytime Running Lamp (DRL)
system is removed, relocated, ormodified.
110 U.S.Requirements:
The statement below is applicable to all incomplete
vehicles with a GVWR of 4536 kg [10,000 lbs] or
less:
This incomplete vehicle does not comply to FMVSS
110. In order to comply, the final stage manufacturer
must affix a tire placard as specified in paragraphS4.3
of FMVSS110.Thedecalmust beaffixed to theB-Pillar.
Seebelow forplacardcontent andnotecolorand format
requirements inS4.3.
108
(Continued)
111 Thestatementsbelowareapplicable to the incomplete
E-SeriesVanwithnodriver-seatwhenequippedwith
aconvexmirroron thepassenger-side:
This vehicle, when completed, will conform toStandard
111, RearviewMirrors, if:
• The mirrors and their mounts as supplied by Ford
MotorCompany,arenot removed, relocated, replaced,
or altered.
• No structural modifications are made to the body
whichwouldaffect the stability of themirrormounts.
• The Seating Reference Point (see definition on
page 5) and the seat back torso angle of the driver-
seat installed or completed by the subsequent stage
manufacturer are located as shown in Figure C
page 32 corresponding to the particular incomplete
vehicle type.
• Anymodificationsoradditionsmade to this incomplete
vehicle do not adversely affect the driver’s view to
the rear in the outside mirrors along both sides of
the vehicle.
If anyalterationblocks the rear fieldof view through the
insidemirror, Standard111may require that thevehicle
have a flat glass on thepassenger side.
111 The statement below is applicable to the following
incomplete vehicle types when not equipped with
outsidemirrors:
• Cutaway
• E-SeriesBasic (Stripped) Chassis
• IncompleteE-SeriesVan
ConformitywithStandard 111, RearviewMirrors, is not
substantially affected by the design of this incomplete
vehicle; accordingly, Ford Motor Company makes no
representationas to conformitywith thisStandard.
111 The statementsbelow are applicable to theCutaway
whenequippedwithoutsidemirrors:
Conformity with the stability requirements of Standard
111, Rearview Mirrors, is not substantially affected
by the design of this incomplete vehicle; accordingly
Ford Motor Company makes no representation as to
conformity with stability requirements of this Standard.
However, except for the stability requirement, this
vehicle, when completed, will conform toStandard111,
RearviewMirrors, if:
• The outside mirrors and their mounts, as supplied
by FordMotor Company, are installed in accordance
with the instructions that accompany them and they
arenot relocated, replaced, or altered.
• The Cutaway with the School Bus Prep Package is
completed as a school bus and any outside mirrors
(not provided by FordMotor Company) are installed
in conformity with the requirements of Standard 111
for school buses.
�����������
�������������������������
��������������������������������������������
�������������������������������������������������������������������������
�����������������
����������������������������
�������������
����������������
���������
��������
���������
�����
����
������������������
����������������������������
�����
����
�������������
�������������
�������������
�������������
111 Thestatementsbelowareapplicable to the following
incompletevehicle typeswhenequippedwithadriver
seat (includinguntrimmedseat) andaconvexmirror
on thepassenger-side:
• IncompleteE-SeriesVanorWagon
This vehicle, when completed, will conform toStandard
111, RearviewMirrors, if:
• The mirrors and their mounts as supplied by Ford
MotorCompanyarenot removed, relocated, replaced,
or altered, except as noted below.
• No structural modifications are made to the body
whichwould affect the stability of themirrormounts.
• Anymodificationsoradditionsmade to this incomplete
vehicle do not adversely affect the driver’s view to
the rear in the outside mirrors along both sides of
the vehicle.
• Thedriver-seat isnot replaced, relocated, ormodified
other than for the addition of seat trim.
If anyalterationblocks the rear fieldof view through the
insidemirror, Standard111may require that thevehicle
have a flat glassmirror on the passenger side.
