STATEMENTSOFCONFORMITY
108 Thestatementsbelowareapplicable to the following
incompletevehicle type:
• Cutaway
This vehicle, when completed, will conform toStandard
108, Lamps, Reflective Devices, and Associated
Equipment, if all the required lighting equipment as
indicated inTableGon thispage (identifiedby thecodes
D,RandS) isdesignedand installed inaccordancewith
the requirements of Standard 108 and the directions
contained in thisstatement.Additionally, if thecompleted
vehicle overall length is 9.14meters [30 feet] or more,
intermediate side marker lamps and reflex reflectors
(not suppliedbyFordMotorCompany)arealso required
for compliancewithStandard 108.
The items of equipment which are supplied by Ford
Motor Company (identified by the code S in Table G,
on this page) are designed and installed to conform to
all the requirements of Standard 108. The completed
vehicle will conform with these components if the
subsequent stage manufacturer does not remove,
relocate, alter, or modify such equipment or modify the
power supply or wiring to such equipment, and does
not complete the body in such a configuration as to
impair the visibility and conformity to the photometric
requirements of the installed lamps and reflective
devices.
Specific requirements for lighting and associated
equipment are listedby incompletevehicle type inTable
Gon this page.
Lamps, reflective devices, and associated equipment
necessary to complete the vehicle from an incomplete
vehicle must conform to the equipment, locations,
special wiring, visibility, photometric, and performance
requirements of Standard 108 and to the applicable
SAE standards or recommended practices referenced
or sub-referenced in thisStandard.
All electrical equipment added to the vehicle by
subsequent stage manufacturers must conform to the
wiringpracticesset forth in theElectricalWiringSection
of theFordTruckBodyBuilders Layout Book.
108 Thestatementsbelowareapplicable to the following
incompletevehicle types:
• IncompleteE-SeriesVanorWagon
This vehicle, when completed, will conform toStandard
108, Lamps, Reflective Devices, and Associated
Equipment, if the subsequent stagemanufacturer does
not:
• Remove, alter, replace, or relocate the lighting
equipment installedon the incomplete vehicle
• Modify the power supply or wiring to such equipment
• Add any additional external lighting equipment
• Increase the overall width of the vehicle beyond that
of the incomplete vehicle
• Complete,modify, oraddcomponents to thevehicle in
suchamanneras to impair thevisibilityandconformity
to thephotometric requirementsof the installed lamps
and reflectivedevices
108
(ContinuedNext Page)
TABLEG
Standard 108LightingEquipment
E-Series
Completed
asTruck,
MPV,Busor
School Bus
Headlamps
S
S
Tail Lamps
R/D
R/D
Stop Lamps
R/D
R/D
Center HighMounted
StopLamp (CHMSL)
R
N
LicensePlate Lamps
R/D
R/D
ReflexReflectors
–SideFront
S
S
–SideRear
R
R
–Rear
R
R
SideMarker Lamps
–Front
S
S
–Rear
R
R
Back-Up Lamps
R/D
R/D
TurnSignal Lamps
–Front
S
S
–Rear
R/D
R/D
TurnSignal OperatingUnit
S
S
TurnSignal Flasher (2)
S
S
Vehicular HazardWarningSignal
OperatingUnit
S
S
Vehicular HazardWarningSignal
Flasher
S
S
Identification Lamps
–Front
N
R
–Rear
N
R
Clearance Lamps
–Front
N
R(1)
–Rear
N
R
Parking Lamps
R
N
School Bus Lamps andSwitches
R
R
(School Bus except Multifunction
School ActivityBus)
S Required on completed vehicle and supplied with the
incomplete vehicle.
R Required on completed vehicle and not supplied with the
incomplete vehicle.
N Not required for completed vehicle.
D Required on completed vehicle and available as an option
(either on vehicle or shipped indunnage).
(1) If a secondunit bodywidth isgreater than2032mm [80 in] or
higher than thecutawaybody, additional clearance lampsmay
be required that complywith this standard.
(2) Designed for two turn signal lampsper vehicle side (one front
and rear). If additional lamps are required, replace the turn
signal flasher with onehaving the correct lamp load rating.
