E-SERIES
(May, 2004)
17
STATEMENTSOFCONFORMITY
106 The statement below is applicable to all incomplete
vehicle types:
This vehicle, when completed, will conform toStandard
106,BrakeHoses, if thebrakehoseassembliessupplied
by Ford Motor Company are not removed, relocated,
altered, or modified and if no brake hose assemblies
are added.
108 In addition to the statementspertaining toparticular
incomplete vehicle types which follow on pages
18 and 19, the statements immediately below,
concerningStandard108Lamps,ReflectiveDevices,
and Associated Equipment are applicable to all
incompletevehicle typesexcept theBasic (Stripped)
Chassis:
No additional components may be added to the
vehicle which require the use of tools to remove such
components, foraccess to theheadlampaimingdevices
as provided by FordMotor Company.
Daytime Running Lamps (DRL’s); Light Trucks for sale
or use in Canada are equipped with DRL’s that meet
the Canadian DRL requirements. As manufactured for
Canada, theE-Seriesvehicleswillmeet theFMVSS108
requirement for DRL’swhenDRL’s are provided.
Conformity with Standard 108, S.12, Headlamp
Concealment Devices, are not substantially affected
by the design of this incomplete vehicle; accordingly,
Ford Motor Company makes no representation as to
conformitywith thisStandard.
108 The statement below is applicable to the following
vehicle type with a GVWR of 4536 kg [10,000 lb] or
less and a vehicle width less than 2032mm [80.00
in]:
• Cutaway
This vehicle, when completed, will conform toStandard
108, Lamps, Reflective Devices, and Associated
Equipment if a Center High Mounted Stop Lamp
(CHMSL) is installed so itmeets all the requirements of
this standard and is connected to the electrical power
source as provided by Ford Motor Company. See the
figurebelow for circuit location.
CENTERHIGH-MOUNTEDSTOPLAMP (CHMSL)
ELECTRICALCONNECTORLOCATION
TO INSTALL “CHMSL”
UNWRAPTAPEFROM
HARNESS INTHISAREA
ANDREMOVE JUMPER
CONNECTIONTOEXPOSE
THE “CHMSLCONNECTOR”.
E-SERIESCUTAWAY
FRONT OF
VEHICLE
THE “CHMSL” ELECTRICALCONNECTIONFOR
ANECONOLINEBASIC (STRIPPED) CHASSIS IS
PROVIDED INADETAILEDSCHEMATICWHICH
ISPACKAGEDWITHTHEBODYBUILDER
ELECTRICALCONNECTORS.
