The cover of this manual identifies the three incomplete
vehicle configurations for which compliance representations
are contained in this manual. Also, a label is affixed to the
cover which includes theVehicle Identification Number (VIN)
for thespecificvehicle towhich thismanual belongs.The label
identifies the following information which pertains only to the
vehiclewith the correspondingVIN.
• TheGVWR
• The front and rear GAWRs
• Tire andwheel size
• Cold tire inflationpressure (kPa/PSI)
• Completed vehicle type(s) into which the incomplete
vehiclemay bemanufactured
• Optional prep packagewhen the vehicle is so equipped
INCOMPLETEVEHICLELABEL
All E-Series incomplete vehiclesmanufacturedbyFordMotor
Company will have an incomplete vehicle label affixed to the
driver-door lock pillar, except Basic (Stripped) Chassis. The
incomplete vehicle label for the Basic (Stripped) Chassis is
affixed to the front structure.Thesample labels, shownbelow,
are typical of that provided.
The 5th, 6th, and 7th digits of the Vehicle Identification
Number (VIN) will identify the incomplete vehicle type.These
three digits are used in the Completed Vehicle Types charts
on page 8.
California Air Resources Board (CARB), requires a Vehicle
IdentificationNumber (VIN) Label having a non-contact, bar-
code, reading wand capability. The bar-code directly below
the VIN on the incomplete vehicle label, when provided, will
complywith this regulation.Seepage51 for locationandother
requirements.
The Canadian Motor Vehicle Safety Act and Regulations
require installation of an incomplete vehicle certification label
with theNational Safetymark on it on vehiclesmanufactured
for sale inCanada.A label representativeof those installedby
FordMotor Company assembly plants is shownbelow.
OPTIONALPREPPACKAGES
Incomplete vehicles produced by Ford Motor Company,
in some instances, are equipped with an optional prep
package. These include the Ambulance Prep, School Bus
Prep,MotorhomePrep, andShuttleBusPrep.The completed
vehicle type chartsonpage8will identify incomplete vehicles
and the optional prep packages or trim codes that may be
required by FordMotor Company if final stagemanufacturers
wish to relyon theStatementsofConformityor, insomecases,
preserve theFordMotor Company new vehiclewarranty.
If an incomplete vehicle is equipped with an optional prep
package, both the incomplete vehicle label affixed to the
vehicle and the label on the front of this manual will identify
theprep package.
INCOMPLETEVEHICLELABELS
