STEP 4
Locate the power cord coming from the Go Power Inverter and going to the GFI
plug in the patient compartment. Cut this cord being sure to leave enough length
to allow for rerouting to connect to the “Transfer Switch Inverter Only” harness
above the breaker box. Install the supplied female extension cord receptacle onto
the Inverter cord and plug into the “Transfer Switch Inverter only” plug. Secure
with supplied zap strap.
Wire coming from the
Go Power Inverter
Transfer Switch Inverter Only plug
Install the cord receptacle and plug
into Transfer Switch Harness.
Black wire to Copper screw
White wire to Silver screw
Green wire to Green screw
