3 / 8
110 VOLT TRANSFER
SWITCH INSTALATION
November 6, 2017
Page
3
of
8
BC Ambulance Service, Fleet Operations
1 877 652-7465
Block C, 2261 Keating X Road
Fax: 250 952-0275
1. Temporarily install the supplied
mounting plate in the location shown.
Use the breaker box faceplate cover
screws to secure the mounting plate.
STEP 2
2. Using the mounting plate as a template,
drill two 1/8
”
pilot holes in the wall and
install the supplied mounting screws.
3. Install the Transfer Switch to
the mounting plate using the
supplied four screws.
