MODULARBODYREMOVAL
Once again, perform a quick check to ensure that there are no significant problems in removing the
modular body from the chassis.
Remove theGrille assembly from the front of the chassis.
Having done this, we recommend that the vehicle be raised by a four-point hoist (to have total and
unobstructed view of the underside of the chassis) and that the removal or disconnection of
underchassis components begin. Items thatmust bedisconnected include;
- removeheat shields as appropriate
- heater hoses anddrain system
- air conditioninghoses (don't forget to evacuate the system)
- under chassis electrical harnesses, both factoryand conversion
- remove the body to chassis ground strap and or other wires that may be attached to the
chassis.
- remove the conversionbumper and towhooks
- disconnect gas filler lines
- remove runningboards
- remove the rear mud flaps to provide better clearances when removing the body from the
chassis.
All underchassis and under hood components are ideal candidates for replacement due to the
extremes in temperature andweather that theyare subjected to.
Lower the ambulance andprepare for thenext phaseof thebody removal process.
