Y. DUBÉ
1
2
4
3
Locate the area damaged by the spring clip.
Drill 1" the web of the channel,
as close as possible to the bottom flange.
Using a reciprocating saw or equivalent tool,
cut the flange flaring the bottom.
Using a reciprocating saw or equivalent tool,
cut the flange flaring the bottom.
DRIVER SIDE.
REAR SPRING UPGRADE MODIFICATION
2012-07-04
0
# 00804
1/4
