6 / 8
110 VOLT TRANSFER
SWITCH INSTALATION
November 6, 2017
Page
6
of
8
BC Ambulance Service, Fleet Operations
1 877 652-7465
Block C, 2261 Keating X Road
Fax: 250 952-0275
FROM UPPER SHORELINE PLUG
TO PATIENT COMPARTMENT
FRONT 110v RECEPTACAL
TO BATTERY CHARGER
TO RIGHT REAR
COMPARTMENT
110v RECEPTACAL
H
E
A
T
E
R
FROM LOWER SHORELINE PLUG
C
H
A
R
G
E
R
H
E
A
T
E
R
O
U
T
L
E
T
S
PROwatt SW
TRANSFER SWITCH
CONNECT TO AC SOURCE POWER
CONNECT TO INVERTER
CONNECT TO AC LOAD
STEP 5:
Recheck that all the new
connections match this diagram.
Ensure all Marret connections are taped
with electrical tape, and all screw
connections are tight.
