110 VOLT TRANSFER
SWITCH INSTALATION
November 6, 2017
Page
2
of
8
BC Ambulance Service, Fleet Operations
1 877 652-7465
Block C, 2261 Keating X Road
Fax: 250 952-0275
Locate the 110V electrical breaker box in the side
electrical compartment.
The layout of the components may differ
between vehicles. Please relocate any
components that interfere with this modification.
Add .3 to labour time if relocation is required.
Contact Fleet Operations with any questions.
1 877 658-7465
Remove the 2 lower cover screws.
Unplug the 2 RC plugs.
Temporarily mount the supplied bracket to the
lower breaker box screw locations using the two
supplied screws.
Using the bracket as a template, drill two 5/32”
holes for the lower mount and loosely install the
supplied screws. (This will allow bracket to tip out
from breaker box when the upper screws are
removed.)
Mount the Transfer Switch to the bracket with the
supplied screws.
Remove the 2 upper bracket screws and allow the
bracket to tip out from the breaker box.
Reconnect the 2 RC plugs.
STEP 1
