Operating Instructions
Vehicle
Page4-5
Crestline
Manual
3/15/2010
Coach
MedicalControlCentre
TheMedical Control Centre or MCC is located at the front of the left side cabinets in the patient
compartment. TheMCC is thedesignated location for the following.
Oxygenoutlets.
Suction system.
Attendant switchpanel.
Thermostat.
Incubator plug.
12Volt outlet.
VolumeControl forOEMAM/FMRadio.
SwitchPanel FunctionsExplained
LEFTCOT------------- this two-position switch controls the left bank or street side cot lights. "Up"
activates the lights at their brightest while "down" activates the dim setting.
Themiddleposition is "off".
RIGHTCOT----------- same as the LEFT COT but this switch controls the right bank or curbside
cot lights.
SUCTION ------------- activates the suctionunit. Please refer to theOEM sectionof thismanual for
additional details.
HEAT/ACFAN------- this two-position switch controls theHeater andAirConditioning.
EXHAUSTFAN------ this switch controls the exhaust fan, whichvents the patient compartment. It
has a high andmedium setting. The fans will run on low speed constantly
withvehicle ignition.
READINGLIGHT --- this switch turns the reading light onandoff.
CENTERCOTLIGHT this switch turns the two center lights on andoff.
SPARE ---------------- a switch for future expansionas required.
