Driver’sConsoleandSwitchFunctions
Your Ambulance has been equipped with a state of the art driver control console. The driver
console is located in the front cab and is attached to the engine cover. This console contains the
following functions.
AMBCONNECT----- activating this switch engages the ambulance conversion electrical power.
This switchmust be "ON" to use anyof the non-chassis functions. Also, the
engine has to be running in order to operate any of the conversion functions
other than theones controlledby theLifeSupport Solenoid and strobe lights.
STROBE--------------- has two settings. Use high during day and low during night. The switch
activates all strobe emergency lights currently installed for this function.
FLASHER ------------- activates all halogen flashing emergency lights currently installed for this
function. (These lightsoperatewhen thevehicle isnot running.)
LIGHTBAR----------- activates the light barmountedon the front and rear of thebox.
WIGWAG------------- activates the wig wag headlights, causing them to flash in an alternating
pattern.
SURESTART -------- activation of this switch will allow the ambulance conversion battery to be
used as aboost assist for the chassis battery supply.
BACK-UP ------------- activation of this switchwill disengage the backup alarm for approximately
60 seconds.
REARTEMP---------- supplies power to the patient compartment hot water heater. The actual
heater function is dependent on the setting of the patient compartment
thermostat. Heater output ispre-set to "HIGH".
AUX. LIGHTS-------- Thehighbeamsmust beon inorder for this switch to activate thedriving
(FOG /DRIVING) lights. Thepark lightsmust beon inorder for theFogLights to function.
LEFTSCENE--------- turningon this switchwill activate the left side (street side) scene lights.
REARSCENE -------- this switch controls the rear scene / loading lights.
RIGHTSCENE------- this switch controls the right side (curb side) scene lights.
COTLIGHTS--------- activation of this switch will engage the left side patient compartment cot
lightson the low setting
SPARE ----------------- for future switch.
