33
Description&Part #’s
Heater Components Face Lift “SC” Heaters
Ref. No. Description Part Number
HYDRONIC 4 / 5WSC - Face Lift - 12 volt - Diesel &Gasoline versions
1 Outer casing 25 2149 01 01 01 • • • • •
2 Combustion air blower with cover 20 1819 99 16 00 • • • • •
3 Cover 25 1917 01 00 02 • • • • •
4 Burner 20 1818 10 00 00 • •
25 2216 10 00 00 • • •
5 Heat exchanger 25 2149 06 00 01 • • • • •
6 Control unit 22 5201 03 00 02 •
22 5201 03 00 01 •
22 5201 00 20 04 •
22 5201 01 90 02 • •
7 Cover 20 1752 99 01 03 • • • • •
8 Coolant Pump 25 2219 25 00 00 • • • • •
9 Fuel metering pump 22 4504 03 00 00 • •
Internal fuel pipe 25 2118 01 00 01 •
Intermediate piece 25 2137 01 00 01 •
10 Integrated fuel filter 20 1312 00 00 06 • • • • •
11 Holder fuel metering pump 25 1917 01 00 07 • •
25 2137 01 00 01 •
12 Seal 20 1820 99 00 01 • • • • •
13 O-Ring 320 75 104 • • • • •
14 Glow pinwith cable section 25 2106 01 10 00 • • • • •
15 Plug connection 20 1752 01 10 00 • •
25 2147 01 14 00 • • •
16 Atomizing ScreenW/O rings 20 1752 99 01 02 • •
25 2121 99 01 13 • • •
17 Holder 20 1752 01 00 04 • •
18 Groomet 20 1752 01 00 02 • •
19 Flame sensor 25 1920 35 00 00 • • • • •
20 Overheat sensor with cable section 25 2147 01 20 00 • •
25 2219 01 20 00 • • •
21 Plug kit 14 pin 22 1000 30 10 10 • • • • •
22 Cable sectionWaterpump 20 1753 01 18 00 • • • • •
23 Spring leaf 25 1922 01 00 05 • • • • •
24 Cover fuel metering pump 25 1752 01 00 03 • •
25 1917 01 00 03 • • •
25 O-Ring 14 x 2.6 22 1000 70 00 06 • • • •
26 O-Ring 7 x 2 22 1000 70 00 09 • • • •
27 Hose 25 1917 01 00 11 • •
28 Cable band 209 31 071 • •
Model #25 2257 05
12v
25 2219 05
12v
20 1820 05
12v
20 1824 05
12v
25 2325 05
12v
