Maintenance / Troubleshooting / Repair

Flame sensor, For removal of tab receptacles, use

AMP extractor tool

CableHarness

Electricmotor, complete

Combustion chamber with flame tube

Heat exchanger and jacket, Align slot on heat

exchanger (arrow) with lug in jacket
