Description&Part #’s
Ref. No. Description
Part Number
Model #
20 1819 05
12v
25 2218 05
24v
25 2217 05
12v
Heater Components
Face Lift “S” Heaters
HydronicB5 / D5 - 12& 24 volt - Diesel &Gasoline versions
1 T-piece
262 31 151
• • •
2 Fuel pick up
20 2900 20 20 56
(CA0 12 056)
•
3 Fuel filter
25 1226 89 00 37
•
4 Fuel hose 3.5 x 3mm
360 75 300
•
4a Hose
---------------
5 Hose 5 x 3mm
360 75 350
• •
---------------
•
6 Plastic fuel line 1.5mm
890 31 118
• • •
7 Plastic fuel line 2mm
890 31 125
• • •
8 Hose 7.5mm
---------------
• • •
9 Supporting sleevewith collar
122 1000 20 02 00
• • •
10 Clamp 11mm
10 2068 01 10 98
• • •
11 Hose clamp 9mm
10 2068 00 90 98
• • •
12 Hose clamp 14mm
10 2068 01 40 98
• • •
13 Hose clamp 12mm
10 2068 01 20 98
• • •
14 Fuel metering pump
12V
22 4517 04 00 00
• •
24V
25 1942 45 00 00
•
15 Fuel Basket Filter
20 1312 00 00 06
• • •
16 Holder metering pump
22 1000 50 03 00
• • •
17 Main harness - J.EUniversal w/relay
25 1917 80 10 00
• •
25 2009 80 10 00
•
17a Main harness ESPAR
20 2900 70 05 02
(CA0 60 502)
• • •
18 Connector kit
22 1000 30 10 21
• • •
19 Relay
12V
203 00 065
• •
24V
203 00 066
•
20 Cable
22 1000 31 28 00
• • •
21a Fuse holder, receptacle housing
22 1000 31 06 01
• • •
21b Fuse holder, cover
22 1000 31 06 02
• • •
22 Fuse
25 A
204 00 089
• • •
20 A
5670055
(CA1 07 005)
• •
15 A
5670053
(CA1 07 002)
•
5 A
204 00 079
• • •
23 Terminal Fe
206 52 136
• • •
24 Terminal Fe
206 00 182
•
25 Terminal Fe
206 52 133
• • •
26 Terminal Fe
206 52 134
• • •
27 Eyelet
Hardware
• • •
28 Eyelet
Hardware
• •
29 Cable band
25 1801 80 02 00
• • •
30 Combination bracket, fuses and fan relay
22 1000 51 21 00
• • •
