41
Description&Part #’s
Ref. No. Description Part Number
Model #20 1819 05
12V
25 2218 05
24V
25 2217 05
12V
1 Casing 25 2149 01 01 01 • • •
2 Combustion air blower with cover 20 1819 99 16 00 • •
25 2146 99 17 00 •
3 Cover 25 2217 01 00 01 • • •
4 Burner 20 1818 10 00 00 •
25 2216 10 00 00 •
25 2146 10 00 00 •
5 Heat exchanger 25 2149 06 00 01 • • •
6 Control unit 22 5201 00 20 04 •
22 5201 01 90 02 •
22 5202 00 10 03 •
7 Cover - heater base 20 1756 99 01 03 • • •
8 Cover 25 2216 01 00 02 • • •
9 Hose barb assly 18mm 25 2216 99 01 06 • • •
10 Hose barb assly - 90° - mm 25 2216 99 01 05 • • •
11 O-Ring 16x2 22 1000 70 00 05 • • •
12 Hose barb locks 25 2216 01 00 10 • • •
13 Gasket / seal set 20 1820 99 00 01 • • •
14 O-Ring - 74x3 22 1000 70 00 02 • • •
15 Glow pin 25 2106 01 10 00 • •
25 2107 01 10 00 •
16 Glow plug connection 20 1756 01 10 00 • •
25 2121 01 14 00 •
17 Glow pin lining and 2O-rings 20 1752 99 01 02 •
25 2121 99 01 13 • •
18 Flame sensor 25 1920 35 00 00 • • •
19 Holder 20 1752 01 00 04 • • •
20 Over heat sensor with cable 25 2150 01 20 00 • • •
21 Grommet for cable 25 2216 01 17 01 • • •
22 Control unit plug kit 22 1000 30 10 10 • • •
23 Water pump harness 25 2009 01 15 00 • • •
24 Spring 25 1922 01 00 05 • • •
25 O-ring 7 x 2 22 1000 70 00 09 • • •
26 Grommet 20 1756 01 00 04 • • •
27 Taptite screwM5 x 12 torx 109 10 153 • • •
28 Taptite screwM5 x 25 torx 109 10 152 • • •
29 Cheese-head screwM5 x 65 torx 100 10 350 • • •
30 Taptite screwM5 x 16 torx 109 10 151 • • •
31 Taptite ScrewM4 x 10 torx 109 10 150 • • •
32 Countersunk screwM5 x 12 torx 102 10 302 • • •
Heater Components Face Lift “S” Heaters
HydronicB5 / D5 - 12& 24 volt - Diesel &Gasoline versions
