Description&Part #’s
Ref. No. Description
Part Number
Heater Components
Face Lift “SC” Heaters
Hydronic 4 / 5WSC - Face Lift - 12 volt - Diesel &Gasoline versions
1 Combustion air hose - 20mm x 1mtr
360 00 099
• • • • •
Double-pipe LW 19, sound damping
---------------
• • • • •
2 End cap
25 1688 80 12 01
• • • • •
3 Hose clamp 16 - 32mm
10 2067 01 60 25
• • • • •
4 Exhaust hose - 25mm x 1mtr / cap
25 1774 80 02 00
• • • • •
5 Exhaust hose 25mm
360 61 299
• • • • •
6 Exhaust end capw/bar
25 1729 80 06 00
• • • • •
7 Exhaust silencer
25 1864 81 01 00
• •
22 1000 40 09 00
• • •
8 Exhaust clamp
22 1000 50 05 00
• • • • •
9 “P” clamp 28mm
152 10 051
• • • • •
10 “Z” bracket
20 1533 88 00 07
• • • • •
11 Water Hose - Moulded - 18mm
20 1690 81 00 01
• • • • •
12 Water hose union - 18mm
20 1528 88 00 03
• • • • •
13 Water hose union - 18mm - 15mm
20 1645 80 02 01
• • • • •
14 Hose clamp 20 - 32mm
10 2065 02 00 32
• • • • •
25 2257 05
12v
20 1824 05
12v
25 2219 05
12v
20 1820 05
12v
Model #
25 2325 05
12v
