INVERTER MODIFICATION
INSTALL THE RELAY SUPPORT AND RELAY WITH SCREW, REINSTALL THE INVERTER COVER.
TIE THE HARNESS WITH ONE (1) ADHESIVES CLIPS AND TIE-WRAP.
SEAL WITH BLACK SILICONE.
NOTE :
SEAL WITH
BLACK SILICONE
