INVERTER MODIFICATION
¢
MARK THE POSITION OF THE TWO HOLES.
USE A 1/8" DRILL BIT FOR THE FIRST HOLE AND 3/8" FOR THE SECOND HOLE.
INSTALL THE CABLE HOLE GROMMET IN THE SECOND HOLE.
SECOND HOLE
FIRST HOLE
REMOVE THE INVERTER COVER.
1½"
1½"
2½"
INSTALL THE CABLE HOLE GROMMET
