Y. DUBÉ
RED/BLACK
F.ALT
BREAKER
15A
15A
FUSEBOX
UNDER DRIVER SEAT
SERIE 628XX
Locate and remove the circuit breaker
on the red / black wire (F.ALT)
Install new supplied circuit breaker
(E307400)
Alternator feed circuit breaker modification
1/2
# 00863
2013-03-13
0
