Clean the surfaces to be painted.
Apply black paint as shown.
Install the new axle as shown.
Install the retaining ring using appropriate tool as shown.
Let dry 10 minutes.
Use a file to remove sharp edges.
2011-09-22
3/4
0
# 00758
O2 CART AXLE REPLACEMENT
