SECOND STRETCHER RELEASE
MECHANISM REPLACEMENT
1
2
4
3
6
5
Use the provided parts to make modification.
Cut the sheath and cable here.
Cut the cable here.
Remove the holding clips holding the old sheath.
(Make sure to notice the course of the sheath).
Remove the release system (6 bolts).
Actual setting of second stretcher release system.
