ESPAR HEATER ACTIVATION
MODIFICATION
TO REMOVE THE CONSOLE PANEL, LOCATE AND UNSCREW THE SIX (6) SCREWS AS SHOWN.
REMOVE THE REAR CONSOLE TO HAVE ACCESS TO THE HEATER SWITCH AND RELAY.
3
4
SPARE SWITCH
