Y. DUBÉ
9
10
11
BEFORE MODIFICATION
AFTER MODIFICATION
ELECTRICAL COMPARTMENT (G1).
Locate the orange wire M10J1-4 on the picture # 10.
Cut and insulate both ends of the orange wire M10J1-4 as shown on picture # 11.
M10J1-4
AIR CONDITIONING MODIFICATION
MX151D 2011 SERIES 629XX
# 00754
0
3/3
2011-09-08
