INTERSECTION LIGHT « STEADY-BURN »
DEACTIVATION FEATURE
(UNIT 63030 TO 63092, 63100 TO 63164, 63200 TO 63264)
This modification is for unit number
63030
to 63092
63100 to 63164
63200 to 63264
1 - Locate connector J3 on module ECU-1.
2 - Remove connector J3 and locate pin 7 - left flasher / pin 8 - right flasher (see diagrams on page 2)
3 - Cut and insulate wires at both ends on pins 7 & 8 (yellow & green wires)
4 - Reinstall connector J3 on module ECU-1.
1
J3
ECU1
