1 - Locate and remove the retaining strap for stair chair.
1 - View of the removed retaining strap for stair chair.
Enlarge the hole using a 5/8" hole saw into the
outer panel only.
Do not enlarge the inner panel.
View of the enlarged hole into the outer panel only.
Close up view of the strap hole
Close up view of the strap hole
STAIR CHAIR BELT MODIFICATION
