DASH AVENGER LIGHT MODIFICATION
4 - Make sure you have the needed item :
Weatherstrip Adhesive (not supplied)
Sealing joint (supplied)
5 - Apply adhesive as shown.
Let Dry 10 Minutes
1 - Remove Avenger light on the windshield.
2 - Clean the surface (windshield).
3 - Remove the Neoprene (sealing joint) on the
Avenger light and clean the surface.
6 - Install sealing joint all around as shown.
9 - The modification is done
Let dry 30 minutes
10 - Reinstall the Avenger light in the vehicle.
4¾"
9"
E204059
E201007
E204059
7 - Apply adhesive in corners.
Let dry 10 minutes
8 - Then press two joint strips together.
