Electrical Information
Vehicle
Page3-4
Crestline
Manual
3/17/2010
Coach
GeneralNotes
ContinuouslyPowerCircuits andComponents
With the vehicle having a dedicated conversion battery system, there are components that have
power to them all the time. For more information on these see their related schematics by
referencing the schematics index in this section.
Inverter
The110-volt inverter is in theECCCompartment.
For further informationon the inverter, seeSection5of thismanual.
ElectricalConnectorCodes
The following tables are provided to assist you in the trouble shootingof electrical problems should
they occur. If you need to call Crestline with an electrical question, please have this information
available as the Service andWarrantyTechnicianwill make frequent references to these tables and
the accompanyingdrawings.
