Driver’sConsoleandSwitchFunctions
Your Ambulance has been equipped with a state of the art driver control console. The driver
console is located in the front cab and is attached to the engine cover. This console contains the
following functions.
AMBCONNECT----- activating this switch engages the ambulance conversion electrical power.
This switchmust be "ON" to use anyof the non-chassis functions. Also, the
engine has to be running in order to operate any of the conversion functions
other than theones controlledby theLifeSupport Solenoid and strobe lights.
STROBE--------------- has two settings. Use high during day and low during night. The switch
activates all strobe emergency lights currently installed for this function.
(The strobe lightsoperatewhen thevehicle isnot running.)
FLASHER------------- activates all halogen flashing emergency lights currently installed for this
function.
LIGHTBAR----------- activates the light barmountedon the front and rear of thebox.
WIGWAG------------- activates the wig wag headlights, causing them to flash in an alternating
pattern.
AUX. LIGHTS-------- Thehighbeamsmust beon inorder for this switch to activate thedriving
(FOG /DRIVING) lights. Thepark lightsmust beon inorder for theFogLights to function.
LEFTSCENE--------- turningon this switchwill activate the left side (street side) scene lights.
REARSCENE-------- this switch controls the rear scene / loading lights.
RIGHTSCENE------- this switch controls the right side (curb side) scene lights.
SPARE----------------- for future switch.
DOORAJARLIGHT alerts you if anyof thedoors arenot closed completely.
DCVOLTGAUGE-- thevolt gauge indicates thevoltage level of the conversionbattery.
SURESTART -------- activation of this switch will allow the ambulance conversion battery to be
used as aboost assist for the chassis battery supply.
BACK-UP ------------- activation of this switchwill disengage the backup alarm for approximately
60 seconds.
DOORS ---------------- controls the lockingandunlockingof all doors on theAmbulance
(LOCK /UNLOCK)
