Connector Index
DRAWING # LOCATION Connector PINS
Electrical Information
ECCBoard 502266R00 C412 12
ECCBoard 502348R00 12
ECCBoard 502492R00 12
ECCBoard 502495R00 12
ECCBoard 502502R00 12
ECCBoard 503330R00 12
ECCBoard 502294R00 C413 12
ECCBoard 502497R01 12
ECCBoard 502499R00 12
ECCBoard 502502R00 12
ECCBoard 502251R00 C414 12
ECCBoard 502294R00 12
ECCBoard 502393R00 12
ECCBoard 502492R00 12
ECCBoard 502497R01 12
ECCBoard 502500R02 12
ECCBoard 502502R00 12
ECCBoard 502266R00 C415 12
ECCBoard 502492R00 12
ECCBoard 503785R00 12
ECCBoard 502499R00 C416 12
ECCBoard 503132R00 12
ECCBoard 502497R01 C417 12
ECCBoard 502502R00 12
ECCBoard 502348R00 C418 12
ECCBoard 502499R00 12
ECCBoard 503330R00 12
ECCBoard 502249R00 C419 12
ECCBoard 502250R00 12
ECCBoard 502500R02 12
ECCBoard 503785R00 12
ECCBoard 503785R00 C420 12
ECCBoard 502248R00 C421 12
ECCBoard 502250R00 12
ECCBoard 502255R00 12
ECCBoard 502502R00 12
ECCBoard 502490R00 C422 12
ECCBoard 502294R00 C424 15
ECCBoard 503330R00 15
ECCBoard 503785R00 15
ECCBoard 502403R01 C425 15
ECCBoard 503330R00 15
Conversion 503330R00 C533 3
Conversion 503330R00 C534 2
MCC 503330R00 C535 3
