Connector Index
DRAWING # LOCATION Connector PINS
Electrical Information
inGrille 502499R00 C202 2
inGrille 502499R00 C203 2
inCeiling aboveAttendant Seat 502255R00 C206 2
underdash 502961R01 C208 2
inECC area 502403R01 C209 2
inECC area 502490R00 C212 2
at Floor Level 502498R00 C218 4
Front Console 502348R00 C310 12
Front Console 502499R00 12
Front Console 502502R00 12
Front Console 503132R00 12
Front Console 503785R00 12
Front Console 502248R00 C311 12
Front Console 502254R00 12
Front Console 502294R00 12
Front Console 502492R00 12
Front Console 502497R01 12
Front Console 502502R00 12
Front Console 502595R01 12
Front Console 503132R00 12
Front Console 502266R00 C312 12
Front Console 502348R00 12
Front Console 502492R00 12
Front Console 502495R00 12
Front Console 502502R00 12
Front Console 503330R00 12
Front Console 502294R00 C313 12
Front Console 502497R01 12
Front Console 502499R00 12
Front Console 502502R00 12
Front Console 502251R00 C314 12
Front Console 502294R00 12
Front Console 502393R00 12
Front Console 502492R00 12
Front Console 502497R01 12
Front Console 502500R02 12
Front Console 502502R00 12
Front Console 502248R00 C315 12
Front Console 502266R00 12
Front Console 502492R00 12
Front Console 502499R00 12
Front Console 502502R00 12
Front Console 503785R00 12
ECCBoard 502248R00 C400 12
ECCBoard 502255R00 12
ECCBoard 502490R00 12
ECCBoard 502844R00 12
ECCBoard 503330R00 12
ECCBoard 502266R00 C401 12
Crestline
Coach Monday, February 04, 2008
Vehicle
Manual
Page 3-41
