Page 133
SUPERDUTYF-SERIES
CODE
DESCRIPTION
F-350
F-450
F-550
SRW
DRW
DRW
DRW
DRW
4x2
4x4
4x2
4x4
4x2
4x4
4x2/4x4
4x2/4x4
H701 OFOUTLETPIPETOBOTTOMOFFRAME
— 5.4L/6.8L/6.0L
239 [9.4]
239 [9.4]
239 [9.4]
239 [9.4]
239 [9.4]
L101 WHEELBASE
3576 [140.8]
3576 [140.8]
4186 [164.8]
3576 [140.8] 4186 [164.8] 4795 [188.8] 5100 [200.8] 3576 [140.8]
4186 [164.8] 4795 [188.8] 5100 [200.8]
L103 OVERALL LENGTH
5730 [225.6]
5730 [225.6]
6340 [249.6]
5730 [225.6] 6340 [249.6] 6949 [273.6] 7254 [285.6]
5730 [225.6]
6340 [249.6]
6949 [273.6 7254 [285.6]
L104 FRONTOVERHANG
945 [37.2]
945 [37.2]
945 [37.2]
945 [37.2]
945 [37.2]
L105 REAROVERHANG
1209 [47.6]
1209 [47.6]
1209 [47.6]
1209 [47.6]
1209 [47.6]
L404 BACKOFCABTO OFREARAXLE
1524 [60.0]
1524 [60.0]
2134 [84.0]
1524 [60.0]
2134 [84.0]
2743 [108.0] 3048 [120.0] 1524 [60.0]
2134 [84.0]
2743 [108.0] 3048 [120.0]
L701 MUFFLER LENGTH— 5.4L/6.8L
609.5 [24.0]
609.5 [24.0]
609.5 [24.0]
609.5 [24.0]
609.5 [24.0]
MUFFLER LENGTH
— 6.0L
661 [26.0]
661 [26.0]
661 [26.0]
661 [26.0]
661 [26.0]
L702 MUFFLERREARTO REARAXLE — 5.4L/6.8L
546.5 [21.5]
546.5 [21.5]
546.5 [21.5]
546.5 [21.5]
546.5 [21.5]
MUFFLERREARTO REARAXL
— 6.0L
596 [23.5]
602 [23.7]
596 [23.5]
604 [23.8]
596 [23.5]
606 [23.9]
582 [22.9] 582 [22.9]
586 [23.0] 593 [23.3]
L703 REARSPRINGFRONTEYETOREARAXLE
663 [26.1]
671 [26.4]
663 [26.1]
671 [26.4]
663 [26.1]
671 [26.4]
653 [25.7]
654 [25.8]
L704 REARAXLETO REARSPRINGSHACKLE
BRACKET
748 [29.4]
739 [29.1]
748 [29.4]
739 [29.1]
748 [29.4]
739 [29.1]
757 [29.8]
755 [29.7]
L706 REAROFFRONTSPRINGBRACKETTO REAR
AXLE
536 [21.1]
544 [21.4]
536 [21.1]
544 [21.4]
536 [21.1]
544 [21.4]
525 [20.7]
526 [20.7]
L707 REARAXLETOFRONTOFREARSPRING
SHACKLEBRACKET
648 [25.5]
639 [25.2]
648 [25.5]
639 [25.2]
648 [25.5]
639 [25.2]
645 [25.4]
643 [25.3]
L708 REARSPRINGSHACKLEBRACKETWIDTH
200 [7.9]
200 [7.9]
200 [7.9]
225 [8.9]
225 [8.9]
L709 FRONTSPRINGHANGERBRACKETWIDTH
253 [10.0]
253 [10.0]
253 [10.0]
256 [10.1]
256 [10.1]
L711 OFREARAXLETO OFEXHAUSTPIPE
— 5.4L/6.8L
664.6 [26.2]
664.6 [26.2]
664.6 [26.2]
664.6 [26.2]
664.6 [26.2]
— 6.0L
698 [27.4]
690 [27.1] 696 [27.4]
687 [27.0] 696 [27.4]
687 [27.0]
709 [27.9] 709 [27.9]
705 [27.8] 698 [27.4]
W700 MUFFLERCROSSSECTION— 5.4L
MUFFLERCROSSSECTION
— 6.0L
7 x 9
7 x 9
7 x 9
7 x 9
7X9
195 x 291
195 x 291
195 x 291
195 x 291
195 x 291
W701 DISTANCEBETWEEN ENGINE/VEHICLE
45 [1.8]
45 [1.8]
45 [1.8]
45 [1.8]
45 [1.8]
W702 ENDOFTAILPIPETO VEHICLE— 5.4L/6.8L
ENDOFTAILPIPETO VEHICLE
— 6.0L
948 [37.3]
948 [37.3]
948 [37.3]
948 [37.3]
948 [37.3]
1027 [40.4]
1027 [40.4]
1027 [40.4]
1027 [40.4]
1027 [40.4]
W703 FRAMERAILWIDTH
107 [4.2]
107 [4.2]
107 [4.2]
108 [4.2]
108 [4.2]
W704 REARFRAMEWIDTH
866 [34.1]
866 [34.1]
866 [34.1]
868 [34.2]
868 [34.2]
W705 DISTANCEFROMFRAMETOOUTSIDEOFREAR
SPRINGSHACKLEBRACKET
149 [5.9]
149 [5.9]
149 [5.9]
151 [5.9]
151 [5.9]
W706 DISTANCEFROMFRAMETOOUTSIDEOFREAR
SPRINGHANGERBRACKET
160 [6.3]
160 [6.3]
160 [6.3]
151 [5.9]
151 [5.9]
LC
LC
LC
LC
LC
LC
LC
LC
LC
LC
NOTES
— [ ] DIMENSIONSARE INCHES.
NOTES
—AXLE/TIRE/VEHICLEHEIGHTDATA, PAGES138-139.
NOTES
—GROUNDCLEARANCEDATA, PAGES 148-149.
DIMENSIONALDATA
SUPERDUTYF-SERIES
REGULARCAB
–
CHASSISCAB
2005
MODELYEAR
LC
