GeneralNotes
ContinuouslyPowerCircuits andComponents
With the vehicle having a dedicated conversion battery system, there are components that have power
to them all the time. Below is a list of these components. For more information on these see their
related schematicsby referencing the schematics index in this section.
Anti-theft System, 12 volt Outlets, Two-wayRadio, IncubatorOutlets,MCC light, Fluorescent Lights
(not onall vehicles),ClearanceLights, PowerDoor locks,Heart Interface Inverter, EmergencyBattery
Boost (not onall vehicles).
Inverter
The110-volt inverter is in theECCCompartment.
For further informationon the inverter, see theOEM sectionof thismanual.
ElectricalConnectorCodes
The following tables are provided to assist you in the trouble shooting of electrical problems should
they occur. If you need to call Crestline with an electrical question, please have this information
available as theService andWarrantyTechnicianwillmake frequent references to these tables and the
accompanyingdrawings.
