# ASS :
Y. DUBÉ
DRIVER SIDE.
Remove left rear leaf spring as per workshop manual.
Lay springs on flat surface & install (2) C clamps.
E807242 X 1
LEAF ,477 X 13,50'' X 2 1/2
E807243 X 2
U BOLT 5/8 X 28 INTUB5828
E007115 X 4
WASHER U BOLT 5/8 INTUBW58
E003290 X 4
NUT UPPER INTDN58
E003289 X 1
BOLT
CENTRAL
REG. HEAD
INTCB7680
E003291 X 1
HEX NUT
7/16 UNF
INTUNC716
2
1
3
SUSPENSION MODIFICATION (BC)
K026200
1/2
# 00904
2014-01-24
0
