If necessary, re-route as shown and add protecting piece
(E807930) to prevent rubbing
NOTE : If hose is damaged, contact Demers to order part number (E807931)
If there is a downward loop, shorten hose at filler end
so the path goes straight.
Use collars to make sure hose does not loop down.
FUEL FILLER HOSE VERIFICATION
