STEP WELL REINFORCEMENT
SCREW ""TEK" PAN SQUARE # 10 X ¾ ZP"
Put the screws (11) ""tek" pan square # 10 x ¾ zp" in the same location shown on picture.
Option 2 : Fasten with screws the components.
Option 2 : Fasten with screws the components.
