Service Bulletin #
Questions or comments regarding this service bulletin may be directed to:
Rina Heisler, Marc Bouchard, Allen Elliott or
Exhaust Fan
Mandatory
NewEra XC FleetMax Commander
Please complete the requirements of this ser
Part Cost N/A ................................
Component Issue:
There have been instances where the current resistor has been showing signs of overheating and the
wire connectors becoming discolored. In cases such as this it is recommended to perform the advised
changes.
Details:
The intention of this bulletin is to provide instructions to replace the existing exhaust fan speed resistor
with a new resistor. Once this advisory is completed, the functionality of the exhaust fan is unchanged.
Materials Supplied:
2 – Connector Butt Insulated 14 Gauge Amp Blue
1 – Resistor 100W 1-Ohm (
ccl#
35505)
2 – Bracket Mounting Resistor 100W 1
2 – Connector Right Angle (
ccl#
15264)
2ft – “#64A Exh High” wire (
ccl#
13367)
2ft –“‘#64B Exh Low” wire (
ccl#
13368)
4 – Cable Ties (
ccl#
10561)
Tools Required:
No. 2 Phillips Screwdriver
Side Cutters
Crimp Tool
Wire Strippers
Instructions:
Page 1 of 3
12-03
Revised Sept 4
th
, 2013
Jim Brooks @ 888-887-
Resistor 100 Watt
Advisory Information Only
Legend 138 Legend 158
vice bulletin at your next serv
....................................................... Labor Allowance
(
ccl#
10632)
-Ohm (
ccl#
35506)
0137
6886
Classic Bus
ice.
.5 Hour
