Service Bulletin # 09-04
April 8, 2009
Questions or comments regarding this service bulletin may be directed to:
Erin Francis: Phone 1-604-882-9333
BATTERY TRAY RETAINER, HOLD DOWN BOLT, TERMINAL WASHER
Mandatory Optional Information Only
NewEra XC FleetMax Commander Legend 138 Legend 158 Classic Bus
Vehicles affected
: 62725-62790
Labour Allowance:
.8 hr
Details
This bulletin contains instructions to install
retainers
on the passenger side battery tray,
change the
battery hold down bolts,
and ensure there are
washers
between the battery cable terminals and the
bolts fastening them to the battery. This bulletin is for
GM ambulances only.
1. First, access the passenger side battery. The battery is located at the passenger side entry door
underneath the step well cover. Remove the step well cover bolts and set the cover aside (Fig 1).
Install the retainer up against the battery tray and against the back side of the step well as illustrated in
Figure 2. Tighten the bolt in the retainer to apply pressure onto the battery tray. Tighten the jamb nut to
lock the bolt.
2. Next, remove the bolt from the battery hold down block and discard. Re-secure the hold down block
by installing the supplied ¼”x1 ¾” bolt, ¼” flat washer, and ¼” lock washer (Fig 3).
3. Finally, inspect the battery cable terminals to ensure there is a washer between the cable terminals
and the bolts. If there are no washers, remove the bolts and re-install with washers (Fig 4 & 5). Check
to make sure the battery cable terminals are tight against the battery. Re-install the step well cover.
Using number
09-04
as a reference number, please forward invoices for repairs to:
Dynamic Specialty Vehicles Ltd.
18550 96th Avenue
Surrey, BC V4N 3P9
Thank you
