Crestline Ambulance 110V Shoreline Plug Upgrade
August 10, 2016
Page
1
of
3
BC Ambulance Service, Fleet Operations
1 877 652-7465
Block C, 2261 Keating X Road
Fax: 250 952-0275
AMBULANCE TYPE: Crestline Ambulances
UNITS AFFECTED: All
ISSUE: 110V Shoreline Plug Upgrade
SERVICE PROCDURE:
1. Remove old 110v shoreline plugs located on left side of ambulance (save the retaining screws for
installation of the new shoreline plug)
2. Disconnect the electrical wires
3. Use the wire gauge located on the bottom of the new 110v plug to cut and strip the electrical wires
to the correct length
4. Insert 110v electrical socket assembly into the socket cover assembly with the ground terminal
placed at the 6 o’clock position and install the retaining screws
5. Insert the bare COPPER electrical wire into the hole with the GREEN screw and tighten
6. Insert the BLACK electrical wire into the hole with the BRASS coloured screw and tighten
7. Insert the WHITE electrical wire into the hole with the SILVER coloured screw and tighten
