Operating Instructions
Vehicle
Page4-16
Crestline
Manual
9/20/2007
Coach
SB #06- 01.1
..............................................................................................................................
June 29, 2006
Mandatory Advisory InformationOnly ........................................................ Part Cost
na
LabourAllowance
na
ThisServiceBulletinApplies to theFollowingVehicles
--------------------------------------------------------------------------------------------------------------------------------------------
NewEra XC FleetMax Commander Legend 138 Legend 158 Classic Bus
Other
na
............................................................................................................CommentsMayBeDirectedTo:
JohnMacDonald
General Description
--------------------------------------------------------------------------------------------------------------------------------------------
Door hinge rivet inspection
Details:
Crestline recommends an inspectionof door hinge rivets on all Crestline vehicles in your fleet. Replace
any rivet inwhich the head ismissingby drilling out the remaining rivet shaft witha drill bit no larger than
17/64”, andapplyanew¼” x 5/8” aluminum rivet. To inspect rivets on thedoor sideof the hinge, gently
push the rubber weather seal far enough toexpose the rivet head. Usea flat blade screwdriver topush
against thehead of the rivet toensure its rigidity.
This initial inspection can occur during the vehicle’s next service. Please add this inspectionprocedure to
your preventativemaintenanceprogram so that all rivets areexaminedat least onceevery6-month
period. Thank you.
JohnMacDonald
Customer ServiceLeader
CrestlineCoachLtd
888-887-6886
