GeneralNotes
ContinuouslyPowerCircuits andComponents
With the vehicle having a dedicated conversion battery system, there are components that have
power to them all the time. Below is a list of these components. Formore informationon these see
their related schematics by referencing the schematics index in this section.
Anti-theft System, 12 volt Outlets, Two-way Radio, Incubator Outlets, MCC light, Fluorescent
Lights (not on all vehicles), Clearance Lights, Power Door locks, Heart Interface Inverter,
EmergencyBatteryBoost (not on all vehicles).
Inverter
The110-volt inverter is in theECCCompartment.
For further informationon the inverter, see theOEM sectionof thismanual.
ElectricalConnectorCodes
The following tables are provided to assist you in the trouble shootingof electrical problems should
they occur. If you need to call Crestline with an electrical question, please have this information
available as the Service andWarrantyTechnicianwill make frequent references to these tables and
the accompanyingdrawings.
