Electrical Information
Vehicle
Page3-1
Crestline
Manual
9/20/2007
Coach
TableofContents
Charging/Electrical Systems ............................................................................................................ 3-2
FactoryBatterySystem........................................................................................................ 3-2
DedicatedConversionBattery............................................................................................. 3-2
HighOutputAlternator........................................................................................................ 3-2
Battery Isolator..................................................................................................................... 3-3
Fast IdleThrottleControl..................................................................................................... 3-3
GeneralNotes
ContinuouslyPower circuits ................................................................................................ 3-4
InverterOperation (not on all vehicles)................................................................................ 3-4
ElectricalConnectorCodes.............................................................................................................. 3-4
ECCLayout.......................................................................................................................... 3-5
Connector andWireCodes.................................................................................................. 3-6
CircuitBreakerCodes.......................................................................................................... 3-6
RelaysCodes........................................................................................................................ 3-6
Schematic Index .................................................................................................................................3-7
