MedicalControlCentre
TheMedical Control Centre or MCC is located at the front of the left side cabinets in the patient
compartment. TheMCC is the designated location for the following.
Oxygenoutlets.
Suction system.
Attendant switchpanel.
Thermostat.
Incubator plug.
12Volt outlet.
VolumeControl forOEMAM/FMRadio.
SwitchPanel FunctionsExplained
LEFTCOT -------------this two-position switch controls the left bank or street side cot lights. "Up"
activates the lights at their brightest while "down" activates the dim setting.
Themiddleposition is "off".
RIGHTCOT -----------same as the LEFT COT but this switch controls the right bank or curbside
cot lights.
SUCTION--------------activates the suctionunit. Please refer to theOEM section of thismanual for
additional details.
HEATERFAN---------this switch controls the rear heater. It has ahigh and low setting.
A/CFAN----------------this switch controls theAirConditioning. It has ahigh and low setting.
EXHAUSTFAN------this switch controls the exhaust fan, which vents the patient compartment. It
has a high and medium setting. The fans will run on low speed constantly
withvehicle ignition.
INTAKEFAN---------this switch controls the intake fan, which takes in air from outside the unit
into thepatient compartment. It has ahigh and low setting.
READINGLIGHT---- this switch turns the reading light on andoff.
SPARE
a switch for future expansion as required.
