Driver’sConsoleandSwitchFunctions
Your Ambulance has been equipped with a state of the art driver control console. The driver
console is located in the front cab and is attached to the engine cover. This console contains the
following functions.
AMBCONNECT -----activating this switch engages the ambulance conversion electrical power.
This switchmust be "ON" to use any of the non-chassis functions. Also, the
engine has to be running in order to operate any of the conversion functions
other than theones controlledby theLifeSupport Solenoid and strobe lights.
STROBE----------------has two settings. Use high during day and low during night. The switch
activates all strobe emergency lights currently installed for this function.
(The strobe lights operatewhen the vehicle is not running.)
FLASHER--------------activates all halogen flashing emergency lights currently installed for this
function.
LIGHTBAR-----------activates the light barmountedon the front and rear of thebox.
WIGWAG-------------activates the wig wag headlights, causing them to flash in an alternating
pattern.
AUX. LIGHTS --------Thehighbeamsmust beon inorder for this switch to activate thedriving
(FOG /DRIVING) lights. Thepark lightsmust beon inorder for theFogLights to function.
LEFTSCENE----------turningon this switchwill activate the left side (street side) scene lights.
REARSCENE---------this switch controls the rear scene / loading lights.
RIGHTSCENE--------this switch controls the right side (curb side) scene lights.
SPARE------------------for future switch.
DOORAJARLIGHT alerts you if anyof thedoors arenot closed completely.
DCVOLTGAUGE---the volt gauge indicates the voltage level of the conversionbattery.
SURESTART ---------activation of this switch will allow the ambulance conversion battery to be
used as a boost assist for the chassis battery supply.
BACK-UP--------------activation of this switchwill disengage the backup alarm for approximately
60 seconds.
DOORS ----------------controls the locking andunlockingof all doors on theAmbulance
(LOCK /UNLOCK)
